About WoodSynth
WoodSynth is a synthesizer with 4 independent layers. Each layer is in fact a synthesizer on its own. Each layer has 3 VCO’s plus a samples or wavetable based source, coming from a file or from recording the audio track....
WoodSynth is a synthesizer with 4 independent layers. Each layer is in fact a synthesizer on its own.
Each layer has 3 VCO’s plus a samples or wavetable based source, coming from a file or from recording the audio track.
Up to 16 voices can be set per layer.
Layers can be used in parallel, assigned to a region of the keyboard or used in a sequential mode where the first note(s) on are played by layer 1 and the next note(s) by layer 2 and so on.
This last mode allows to have a different sound per note played (and independent from a keyboard region).
WoodSynth has a polyphonic pitch-bending touch bar which also displays notes received from a keyboard.
Each layer has its own filter and envelope with ADSR per voice, a pitch shifting envelope per VCO, a delay, a basic reverb, a modulator LFO per VCO, 2 general LFO’s and a 16 steps sequencer.
Key tracking can be applied on the ADSR attack and release, on the filter cutoff and on the VCO modulation.
The app can be used stand-alone (device audio input and output) or as a plugin in a DAW.
- IOS plugin type : AUv3 and stand-alone app.
- Has 4 independent synthesizers, each with up to 16 voices.
- Supports MPE and Midi V2.
- Has a polyphonic touch bar with polyphonic pitch bending.
- Velocity, channel pressure, (polyphonic) aftertouch, CC74 can be used to modulate several synth parameters.
- VCO’s have the usual waveforms (sine, saw, square, triangle, pulse and noise) and can be modulated in various ways (FM, AM, Pulse Width, Slew rate)
- Samples can be recorded from the audio input/track or loaded from file (sample files should be in the WoodSynth iCloud folder)
- Wavetables can be loaded from file or converted from loaded or recorded samples.
- Each voice has a 4-pole Moog Lowpass filter with resonance and ADSR envelope.
- An offset can be set in the Filter cutoff for the R channel to create a stereo effect.
- Each voice has a pitch shifting ADSR envelope which can be independently enabled for each VCO.
- Has Key tracking for VCO pan, Filter cutoff, ADSR Envelope Attack and Release.
- Each layer has a delay unit (which can be separately panned) and a basic reverb.
- Each layer has a 16 steps sequencer which can run on multiple voices (poly mode).
- Each layer can set the midi channel and range of receiving midi notes (which allows for up to 4 split keyboard regions).
- Layers can be set in sequential mode : first note(s) played on layer1, next note(s) on layer2, etc.
- Layers have an additional high-pass filter saturation and crush control.
- Synth audio and delay can be panned independently.
- The 2 general LFO’s can have their source from the samples or wavetables (or track input).
- Supports Ableton Link to sync tempo and start-stop.
- Has 4 User Control rotaries which can be freely assigned.
- The User Controls can be controlled by a midi CC which can be set or learned.
- Presets can be stored in iCloud Drive (makes them available on all your devices).
- Supports CV out and Sequencer Midi out.
Feb 25, 2024
Version 3.7
- Fixed display of some parameters in Korg Keyscape keyboards.
- Fixed problem when DAW reloads state which uses a sample file.
- Added a subtle hint to the bottom buttons (in the classic iPad view) that there is a left and right difference.
Previous Versions
Here you can find the changelog of WoodSynth since it was posted on our website on 2021-12-16 05:10:07.
The latest version is 3.7 and it was updated on 2024-04-19 19:24:33. See below the changes in each version.
WoodSynth version 3.7
Updated At: 2024-02-25
Changes: Feb 25, 2024
Version 3.7
- Fixed display of some parameters in Korg Keyscape keyboards.
- Fixed problem when DAW reloads state which uses a sample file.
- Added a subtle hint to the bottom buttons (in the classic iPad view) that there is a left and right difference.
WoodSynth version 3.6
Updated At: 2024-01-18
Changes: Jan 18, 2024
Version 3.6
- Added Midi V2 CI (Capability Inquiry) PE (Property Exchange) support : allows midi v2 CI capable Initiators (keyboards, controllers, WoodTroller, …) to automatically map WoodSynth midi CC parameter names and values to their controls. Also WoodSynth preset names (programs) with their PC and bank and category can be transferred.
- Supports the new Korg Keyscape keyboards with midi v2 CI Property Exchange.
- Added a preset category dropdown which allows to only see a subset of the presets.
- Added new Poly Aftertouch panel which allows multiple destinations.
- Poly Aftertouch / Pressure destinations now have an amount slider.
- Added Aftertouch/Pressure destinations for detuning Oscillators 1,2&3.
- Added Aftertouch/Pressure destination for panning (LR) of Oscillators.
- Added Aftertouch/Pressure destination for ring mod of Oscillators 1&2.
- Added Aftertouch/Pressure destination for crossfade of Oscillators 1&2
WoodSynth version 3.5
Updated At: 2023-10-19
Changes: Oct 19, 2023
Version 3.5
Added Midi V2 support :
- Uses the 16 bits velocity in received v2 note-on/off messages.
- Uses the 32 bits values in received v2 CC, Aftertouch, Pressure and Pitch messages.
- Uses the received new v2 “Per note pitch” messages (v1 MPE equivalent).
- Uses the received new v2 RPN (Registered Per Note) 74 messages (MPE equivalent).
- Uses the new v2 note-on attribute type 3 (Pitch 7.9).
- Sends v2 messages (16 bits velocity, 32 bits control values) when Sequencer midi out or Touch bar midi out is on.
- Responds to Midi V2 CI Discovery and Profile Inquiry messages.
- Added Midi v2 button in Advanced to enable v2 or revert to midi v1.
- Added Midi v2 group dropdown (All, 1..16).
Other new features :
- Added (back) “Remove Preset” in presets menu.
- Selected preset now shows checkmarks on all sub folders.
- Added Undo & Redo (press Alt for Redo button in Classic view).
- Added Compare A/B button (toggles between original preset and modified preset).
- Added Octave Up/Down buttons to touch bar.
- Midi out does not send any longer to its own (WoodSynth) destination.
- Sequencer midi out now also sends :
velocity in note-on messages with value set to the step volume.
CC74 message with value of sequencer step param2.
Mod wheel message with value of sequencer step param3.
Pitch wheel message (Osc1 detune, Sequencer sub semitones, …).
correct note values when using Variations, also with Var Glide on.
WoodSynth version 3.3.6
Updated At: 2023-07-06
Changes: Jul 6, 2023
Version 3.3.6
Fixed loading (via Browse) of sample and preset files outside the WoodSynth folder on iOS.
WoodSynth version 3.3.5
Updated At: 2023-07-04
Changes: Jul 4, 2023
Version 3.3.5
Fixed potential crash when loading sample files and doing sample rate conversion.
Fixed potential crash or hanging when loading presets in AUv3.
WoodSynth version 3.2.1
Updated At: 2023-05-09
Changes: May 9, 2023
Version 3.2.1
fixed Ableton Link on iOS 14
WoodSynth version 3.1.7
Updated At: 2023-04-13
Changes: Apr 13, 2023
Version 3.1.7
- Added slower step times (1/2 bar, 1 bar , … 4 bars) to Sequencer
- CV out now allows to set the output channel (useful when nr out channels > 8)
- Fixed bug in multi-point ADSR Release : releasing the last note did re-trigger the release of the other voices
- Fixed multi-bus out in AUM
- Fixed overload (sometimes no sound) for very low frequency (C1 … ) phase modulation.
- CV out on iOS can now be sent via extra busses (AUM, …)
WoodSynth version 3.1.4
Updated At: 2023-03-24
Changes: Mar 24, 2023
Version 3.1.4
- Fixed severe no-audio problem when Phase Modulation (FM) was switched on and oscillator waveform was switched to noise or pulses.
WoodSynth version 2.6
Updated At: 2022-08-21
Changes: Aug 21, 2022 Version 2.6
Added Wavetable (playback) support :
- Wavetable files can be loaded or any sample file or sample recording can be converted to a Wavetable.
-
Wavetable start position (wave number) can be set and changed/modulated by LFO1, LFO2, note velocity or pressure, note position (key tracking), Expression pedal or Mod Wheel, Aux Envelope, Sequencer, or set to a random number for each new note.
- A new Wavetable display shows an overview (4 waves) and the current wave within the overview.
- The Wavetable can also be used as source for the 2 general LFO’s.
Improved Preset Selection with (system) File selection panel :
- Although this “Browse” panel was already present as item in the Preset dropdown, it now has its own button which makes it always and easily accessible (which was sometimes hard when a preset was selected at the bottom of a long list).
- The (system) File selection panel also allows to rename, delete, copy, move, duplicate and tag a preset file.
The “Add” and “Save” preset also have their own button now (same reason).
- The spacing in the classic Preset dropdown is reduced to display more presets (less scrolling ...).
Added presets : “Riding the Waves” , “Up and Down”, “Caribbean Waves”.
WoodSynth version 2.3.4
Updated At: 2022-03-01
Changes: Mar 1, 2022 Version 2.3.4
- fixed a bug in the Presets menu which made all selections fail (like "Copy factory presets") after a new install
